INSTALLATION
8
Mount the Installation Brackets — Outside Mount for Cassette Shades
■ Center the cassette over the window opening at the desired Concord, North Carolina height.
Use a pencil to lightly mark each end of the cassette.
➤ Alternatively, measure the width of the cassette and use that width to mark the cassette
end points over the window opening.
■ Mark 2" from each end of thecassette.
➤ If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into wood
whenever possible.
■ Center the brackets on your marks and mark the screw holes.
IMPORTANT: The rear of the brackets must be flush against a flat mounting surface. Do
not mount brackets oncurved molding.
■ Use a
3
/ 32 " drill bit to drill holes for the mounting screws.
■ Attach the installation brackets using the screws provided.
IMPORTANT: The front edges of the installation brackets
must be level and aligned to eachother.
WARNING: Product is heavy. Mount into wood/
metal studs or into concrete with concrete anchors.
Drywall anchors are not recommended.
Cassette End Marks
Window Opening
Space EvenlySpace Evenly
2"
2"
2"
