INSTALLATION
6
Mount the Installation Brackets — Outside Mount for Standard Shades
IMPORTANT: To ensure each bracket is mounted properly, the white tab should be at the
bottom.
■ Center the mounting profile over the window opening at the desired height. Use a pencil to
lightly mark each end of the mounting profile.
➤ Alternatively, measure the width of the mounting profile and use that width to mark the
mounting profile end points over the window opening.
■ Mark 1
1
/ 2 " to 3" from each end of themounting profile.
➤ If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into wood
whenever possible.
■ Center the brackets on your marks and mark the screw holes.
IMPORTANT: The rear of the brackets must be flush against a flat mounting surface. Do
not mount brackets oncurved molding.
■ Use a
3
/ 32 " drill bit to drill holes for the mounting screws.
■ Attach the installation brackets using the screws provided.
IMPORTANT: The front edges of the installation brackets must be level and aligned to
eachother.
WARNING: Product is heavy. Mount into wood/metal studs or into concrete with
concrete anchors. Drywall anchors are not recommended.
Proceed to “Install the Shade” on page 9.
Mounting Profile End Marks
Window Opening
Space EvenlySpace Evenly
1
1
/2" to 3" 1
1
/2" to 3"
