INSTALLATION
9
Install the Shade
Standard Installation
The groove on the top of the mounting profile fits into the hooks on the installation brackets.
■ Hold the shade so the bottom bar fabric side faces you.
■ Hook the back groove of the mounting profile onto the hooks of the installation brackets.
■ Rotate the mounting profile toward the white tabs of the installation brackets. Push the set
bar until the tabs lock into place. You will hear a loud click when each bracket is securely
in place.
Cassette Installation
■ Angle the cassette back and then
align the cassette under the front lip
of the bracket.
■ Push the cassette back to snap it
into the lower lip of the bracket.
Hook
Hook
Bracket
Bracket
Mounting
Profile
Mounting
Profile
Inside or Ceiling Mount Outside Mount
Bracket
Front
Lip
Cassette
