INSTALLATION
14
18V DC Power Supply
NOTE: When power is connected to the motor, a blue LED inside
the control button housing will flash to indicate the shade is ready
for operation.
■
Plug the power cable from the shade motor into the extension cable.
■
Plug the other end of the extension cable into the 18V DC power supply.
■
Plug the 18V DC power supply into a power source.
Proceed to “Testing the Shade” on page 16.
from shade motor
Extension
cable
18V DC
Power
Supply
