INSTALLATION
7
■
If using spacer blocks, attach the spacer block(s) and
installation bracket to a flat vertical mounting
surface with #6screws long enough for a
secure installation.
NOTE: The spacer blocks for the rechargeable
battery wand come with #8 screws.
➤
The top of the spacer blocks should be at the
desired shade height.
IMPORTANT: Do not add more than 1
1
⁄
2
" of
clearance using spacer blocks.
IMPORTANT: The tops of the installation brackets must be level with the front
edges aligned.
CAUTION: Use drywall anchors when mounting into drywall.
■
If using extension brackets, attach an installation bracket to
the underside of each extension bracket using the speed nuts
and screws provided.
If you have a headrail-mounted rechargeable battery wand,
proceed to “STEP 2: Attach Rechargeable Battery Mount to Headrail (If
Applicable)” on page 8,
Otherwise proceed to “STEP 3: Install the Shade” on page 9.
1
1
∕
2
"
Maximum
Blocks
Screw
Speed Nuts
Screws
