OPERATION INSTRUMENTS
- 15 -
ENGLISH
SHIFT LEVER
The shift lever is mounted on the left side of the engine. The
position of the gears is shown in the illustration. Neutral, or the idle speed,
is located between first and second gear.
KICKSTARTER
The kickstarter is located on the left side of the engine. The upper part is
tiltable.
FOOT BRAKE PEDAL
The foot brake pedal is located in front of the right footrest. Its basic position
can be adjusted to your seat position (see maintenance work).
SIDE STAND
Push the side stand to the ground with your foot and load it with the motor-
cycle. Make sure that you put your bike on solid ground and in a secure
position.
WARNING: The side stand swings up rapidly when the load
is released. Make sure you are not standing in the way.
2,3,4 (5,6)
1
N
