TECHNICAL DATA - CHASSIS
- 62 -
ENGLISH
FC 450/4, 550/4 FE 450/501/550/650E/6 FS 450E/6, 650E/6
Frame tubular chrome-molybdenum-steel frame, powder-coated
Fork WP Up Side Down 4860 MXMA
Spring travel, front/rear 300/320 mm 295/320 mm 275/288 mm
Rear suspension WP Progressive Damping System shock absorber, aluminum rear swinging fork
Front brake Disk brake,perforated Ø 260 mm brake disk, floating brake caliper Ø 310 mm radial brake caliper
Brake disk front minimum thickness 2,5 mm minimum thickness 5,0 mm
Rear brake Disk brake,perforated Ø 220 mm brake disk, floating brake caliper
Brake disk rear minimum thickness 3,5 mm
Front tire
Air pressure, off road
Air pressure, on road/alone
80/100 - 21“
1,0 bar
–
90/90 - 21“
1,0 bar
1,5 bar
120/60 - 17“
–
1,5 bar
Rear tire
Air pressure, off road
Air pressure, on road/alone
110/100 - 19“
1,0 bar
–
140/80 - 18“
1,0 bar
2,0 bar
150/60 - 17“
–
2,0 bar
Fuel tank capacity 9 Liter
Gear ratio - rear wheel 14:48 16:40 16:38
Chain X-Ring 520
Available rear sprockets 38Z, 40Z, 42Z, 45Z, 48Z, 50Z, 52Z
Lighting Headlight HS1 12V 35/35W
Parking light 12V 5W (Sockel W2, 1x9,5d)
Brake light 12V 21/5W (Sockel BaY15d)
Turn signal 12V 10W (Sockel Ba15s)
Battery maintenance-free battery 12V 7Ah
Steering head angle 63,5° 63° 63,5°
Wheel base 1481 ± 10 mm 1490 ± 10 mm 1481 ± 10 mm
Seat height, unloaded 930 mm 870 mm
Ground clearance, unloaded 380 mm 320 mm
STANDARD ADJUSTMENT - FORK
FC 450/4, 550/4
WP4860MA
14.45.7A.01
FE 450/550/650e/6
WP4860MA
14.45.7A.02
FS 450e/6, 650e/6
WP4860PAMA
14.45.7A.03
Compression adjuster 22 18 20
Rebound adjuster 20 20 15
Spring 4,6 N/mm 4,2 N/mm 4,8 N/m
Spring preload 5 mm 5 mm 0 mm
Airchamber lenght 95 mm 110 mm 110 mm
Fork oil SAE 5 SAE 5 SAE 5
STANDARD ADJUSTMENT – SHOCK ABSORBER
FC 450/4, 550/4
WP 5018 PDS
12.45.7A.01
FE 450/550/650e/6
WP 5018 PDS
12.45.7A.02
FS 450e/6, 650e/6
WP 5018 PDS
12.45.7A.03
Compression adjuster 15 LS (low speed)
2,5 HS (high speed)
15 LS (low speed)
2 HS (high speed)
15 LS (low speed)
2 HS (high speed)
Rebound adjuster 22 22 15
Spring 80/250 80/250 88/250
Spring preload 5 mm 5 mm 11 mm
