OPERATION INSTRUMENTS
- 15 -
FILLER CAP
To open the filler cap: Turn the filler cap counter-clockwise.
To close the filler cap: Put the filler cap on and tighten it by turning
it clockwise.
Install the tank breather hose (1) without kinks.
FUEL TAPS
OFF In this position the fuel taps are closed. No fuel can flow
to the carburetor.
ON/RES The knob is in the ON or RES position when the motorcy-
cle is running. Fuel is conveyed to the carburetor in this
position and the tank will drain completely.
NOTE: The RES function is not available.
CHOKE
If you pull the choke button (2) out as far as possible, a bore in the
carburetor will be opened through which the engine may take in
additional fuel. The result is a „fat“ fuel-air mixture of the type nee-
ded for cold starts. To deactivate the choke, push the choke button
back into its basic position.
HOT START DEVICE
If you pull the hot start device (3) out as far as possible, a bore in
the carburetor will be opened through which the engine may take
in additional air. The result is a „lean“ fuel-air mixture of the type
needed for hot starts.
To deactivate the hot start device, push the hot start button back
into its basic position.
ENGLISH
1
2
3
