OPERATION INSTRUMENTS
- 7 -
COMBINATION SWITCH
The light switch has 2, respectively 3 switch positions.
A = Light off (this function is not available in all models)
B = Low beam on
C = High beam on
You may use button (1) to actuate the horn.
The red short circuit button (2) serves to switch off the engine.
Leave the switch pressed until the engine stops.
FLASHER SWITCH
The flasher switch (3) is a separate unit and is mounted on the left
portion of the handlebar.
The wire harness is designed in a way that whenever you want to
use your bike off-road, you can dismount the entire turn indicator
system without affecting the function of the remaining electrical
system.
Flasher left
Flasher right
IGNITION LOCK
Switch positions of ignition lock:
Ignition off, light off (engine can't be started)
Ignition on, light off (engine can be started)
HEADLAMP SWITCH (USA)
In this model the headlamp is switched on with the pull switch (4).
ENGLISH
A
B
C
1
2
3
4
