Move forward.
Neutral.
Move rearward.
Parking brake, model RC 320Ts AWD.
Speed brake and parking brake, model RC
318T.
Stop the engine.
Start the engine.
Headlights.
Engine speed – fast.
Engine speed – slow.
The auger is in the servicing position.
The cutting deck is not attached.
The collector is full.
The collector hatch is open.
The collector is not lowered.
Status indication lamp for auger system.
Tilt and open the collector.
Lower the collector to the operation position.
Fuel.
Max. ethanol 10%.
Cutting height.
Servicing position for the cutting height
lever.
The blades are engaged.
The blades are disengaged.
Servicing position for the cutting deck.
Mowing position for the cutting deck.
The auger is in operation position.
The auger in servicing position.
Do not step here.
Hydrostatic freewheel.
Oil level.
Risk of crush injuries.
Risk of crush injuries. Keep body parts away
from the equipment frame.
6 63 - 007 - 20.06.2017
