P/N 0501930_A 1-13
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
4. Fasten End Assembly to Merchandiser
a. Use Bolt and washer to fasten end
assembly to merchandiser
b. Use washer with Hex Nut to secure bolt
and washer at front and canopy (Detail A
and B), similar to joining process.
c. Tighten in order shown on previous page.
After fasteners have been tightened, insert
Plug Buttons.
d. Install Top and Bottom Corner Castings
as shown below.
Ultra Low Front
Rear Load Excel
