HydraMaster MAXX 450D - Fig

MAXX 450D/470/Diesel Page 1-91
HydraMaster Corporation
Daihatsu Engine Assembly - Maxx 450 Diesel Parts List
Item Part Number Description Qty
1 000-047-017 Engine, Daihatsu 850 Diesel 1
2 000-109-078 Pulley, CAT Pump Drive 1
3 000-150-052 Shaft, Daihatsu Stub - Maxx 450D/470D 1
4 000-077-010 Key, 1/4" x 1-1/2" Lg. Class 2 Fit 1
5 000-143-185 Screw, 8mm x 20mm Grade 8.8 Hex Head 6
6 000-174-018 Washer, 5/16" Lock 28
7 000-143-083 Screw, 8mm x 30mm Lg. Grade 8 Hex Head 5
8 Fig. 1-42 Assembly, Water To Water Heat Exchanger 1
9 000-015-729 Bracket, Left Front Foot - Daihatsu 1
10 000-015-731 Bracket, Right Front Foot - Daihatsu 1
11 000-015-737 Bracket, Radiator Mounting 2
12 000-015-741 Bracket, Rear Foot - Daihatsu 2
13 000-109-100 Pulley, 6" Dual V Belt - Maxx 1
14 000-143-187 Screw, 8mm x 25mm Lg. Grade. 10.9 Hex Head 17
15 000-174-049 Washer, 5/16" Flat 16
16 000-033-066 Clamp, 3/4" Spring 1
17 000-143-132 Screw, #10-24UNC x 0.75" Lg. Hex Head 3
18 000-174-014 Washer, #10 Lock 1
19 000-174-021 Washer, 3/8" Lock 4
20 000-143-017 Screw, 3/8"-16UNC x 0.75" Lg. Hex Head Grd. 8 4
21 000-174-017 Washer, 1/4" Lock 8
22 000-174-003 Washer, 1/4" Flat 7
23 000-143-077 Screw, 6mm x 20mm Lg. Socket Head 6
24 000-094-038 Nut, 5/16"-18UNC Nylock 2
25 000-020-055 Bushing, H 1-1/8, From Solid Steel 1
26 000-015-721 Bracket, Oil Funnel Support 1
27 Fig. 1-20 Air Pump Assembly - N/S - Maxx 450D/470D 1
28 000-004-001 Alternator, Daihatsu 700G & 950G 1
29 000-154-114 Spacer, Alternator Mounting - Maxx 450D/470D 1
30 000-108-100 Guard, Oil Spill - Raw 1
