MAXX 450D/470/Diesel Page 1-99
HydraMaster Corporation
Maxx 450D/470/Diesel Hose Assemblies
Hose Hose
Part No. Descript.
From To Qty
068-085 Cat Pump Oil Drain Frame 17 in
Modified Chemical Meter Chemical Last-Step Pump 33 in
(078-032) (111-035)
Air Filter Air Pump 22 in
068-086 Cat Pump Fill 16 in
Air Pump (111-085) Air Pump Hose Adapter 8 in
4” x 19” Tube & Shell Heat Ex. Hi PSI Bypass Valve (169-081) 14”
Core (038-031)
Poly Water Box Tank (159-105) 4” x 19” Tube & Shell Heat Ex. 29 in
Core (038-031)
068-103 MagnaClean (163-056) Poly Water Box Tank (159-105) 10 in
068-230 Fuel Line 8 ft
068-250 Water to Water Heat Exchanger Water to Water Heat Exchanger 2 in
(038-043) (038-043)
1” Barb x 1” Barb x 1” Barb Tee 1” Barb x 1” Barb Elbow for 7 in
(052-648) Radiator Hose (052-091)
Radiatior 1” Barb x 1” Barb Elbow 18 in
(052-091)
Thermostat Adapter (001-033) Water to Water Hear Exchanger 32 in
(038-043)
068-326 Chemical Jug Pick-up Modified Chemical Meter 63 in
(074-032)
Chemical Jug Return 3-Way Chemical Valve (169-017) 58 in
068-236 Fuel Line w/Female Quick 10 ft
Connect (450 Diesel)
068-092 Hi PSI Brass Manifold (Out) Hi PSI Brass Manifold (090-010)/
(090-008)
3/8 Check Valve Brass (169-175)
068-511 Hi PSI Brass Manifold After Burner Heat Exchanger
(090-010) (Out) (038-045)
