Page 1-100 MAXX 450D/470/Diesel
HydraMaster Corporation
Maxx 450D/470/Diesel Hose Assemblies
Hose Hose
Part No. Description
From To Qty
068-512 Water to Water Heat Exchanger Hi PSI Bypass Valve (169-081)
(038-043)
068-513 Water to Water Heat Exchanger Water to Water Heat Exchanger
(038-043) (038-043)
068-514 Hi PSI Brass Manifold 12V Solenoid, 1200 PSI Valve
(090-010) (169-082)
068-515 Pressure 0-30 Hg Gauge Hi PSI Bypass Valve
(074-007) (169-081)
068-517 Chemical Metering Valve Chemical Last Step Pump
(169-160) (111-135)
068-518 3-Way Chemical Valve Hi PSI Brass Manifold (Out)
(169-0171) (090-008)
068-519 Poly Water Box Tank (159-105) Cat Pump 7 in
068-521 Steam Chemical Jug Outer Tray Automatic Pump Out (111-012) 24 in
Hose (166-022)
068-522 Blower Silencer (093-082) 3
1/2 in
Final Exhaust Adapter (001-087) Heat Exchanger Core (038-031) 2
1/4 in
068-523
3/8” Hi Temp Oil Drain 17 in
068-525 Water to Water Heat Exchanger After Burner Heat Exchanger (In)
(038-043) (038-045)
068-526 Heat Exchanger Core (038-031) Silencer (093-082) (450D Diesel) 3w in
068-587 3/8” Throb Hose, Cat Pump Hi PSI Bypass Valve (169-081) 17 1/2 in
Throb Hose, Cat Pump Terminus 17
1/2 in
068-612 Poly Water Box Tank Hi PSI Brass Manifold
(159-105) (090-010)
068-620 Heat Exchanger Core (038-031) Silencer (093-082) 4
1/2 in
