HydraMaster MAXX 450D - Hydrahoe Wand Assembly

MAXX 450D/470D/Diesel Page 7-5
HydraMaster Corporation
1/18/00
Hydra Hoe Wand Assembly Parts List
ITEM PART NO. DESCRIPTION QTY
1 173-001 Wand Kit, 12" s/s Truckmount 1
2 082-004 Lips, 12" s/s HM Wand (2 Pieces) 1
3 169-055 Valve Assembly, s/s Hydra Hoe with Trigger 1
4 081-015 Label, “HydraMaster” Wand 1
5 154-001 Spacer, ¼ x
5
/
16
s/s Solution Valve 5
6 168-001 Tube, Hydra Hoe Solution -¼” OD s/s 1
7 061-006 Handle, Pressure Guide 1
8 052-151 Compression,
1
/
8
” Female Hydra Hoe Fitting 1
9 052-153 Housing, Brass Stabilizer Wand Nozzle Fitting 1
10 186-001 Stabilizer - Jet Assembly Group 1
11 076-005 Jet, #6 s/s Hydra Hoe 1
12 094-028 Nut, Brass Jet Assembly Group 1
13 143-005 Screw, ¼ - 20 x 1¾” HHC 2
14 143-012 Screw,
5
/
16
- 18 x ¾” HHC s/s 2
15 094-035 Nut,
5
/
16
- 18 s/s Nylock Half 2
16 094-009 Nut, ¼ - 20 s/s Nylock 2
17 174-032 Washer,
3
/
8
“ s/s Flat 2
18 174-003 Washer, ¼” s/s Flat 4
19 061-007 Handle Grip Hydra Hoe 1
20 063-003 Harness Wrap, High Temp. ¼” - Gray 4
21 076-045 Jet, 8004E s/s T 1
