HydraMaster MAXX 450D - Water to Water HX Assembly - Maxx 450 Diesel

MAXX 450D/470/Diesel Page 1-95
HydraMaster Corporation
Water To Water HX Assembly - Maxx 450 Diesel Parts List
Item Part Number Description Qty
1 000-015-739 Bracket, Dual HX Mounting - Right 1
2 000-015-735 Bracket, Dual HX Mounting Channel 1
3 000-038-043 Heat Exchanger, Water To Water 2
4 000-033-020 Clamp, Size #16 Hose 2
5 000-052-086 Elbow, 3/8" NPT Street 3
6 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 3
7 000-052-083 Elbow, 3/8" NPT Street x 45° 2
8 000-068-250 Hose, 1" Green Stripe - Bulk 1
9 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 8
10 000-174-019 Washer, 1/4" Lock 8
11 000-068-513 Hose Assembly, 3/8" x 10" Teflon 1
12 000-052-131-1 Elbow, 1" NPT - Modified 2
13 000-052-131 Elbow,1"Nptx1"Barb(Glass Filled Black Nylon) 2
14 000-143-181 Screw, 1/4"-20UNC x 3.50" Lg. 1
15 000-174-003 Washer, 1/4" Flat 2
16 000-094-009 Nut, 1/4"-20UNC Hex Nylock 1
