HydraMaster MAXX 450D - Water Box Assembly

MAXX 450D/470/Diesel Page 1-47
HydraMaster Corporation
Item Part Number Description Qty
Water Box Assembly Parts List
1 000-159-105 Tank, Poly Water Box - Modified 1
2 000-015-640 Bracket, Water Box Mounting - Weldment 1
3 000-052-659 Bulkhead, 3/8" Mpt x Straight 1
4 000-097-042 O-Ring, Bulkhead Fitting w/ 3/8" NPT 1
5 000-174-027 Washer, 3/4" Flat 1
6 000-094-096 Nut, 3/4-16 Brass Water Box 2
7 000-169-064 Valve, 3/8" NPT Full Port Ball 1
8 000-052-083 Elbow, 3/8" NPT Street x 45° 1
9 000-052-104 Insert, #66 (3/8" NPT x 3/8" Barb) 1
10 000-052-660 Bulkhead, 3/8" FPT x 3/8" FPT 1
11 000-097-041 O-Ring, 1/2" Bulkhead 2
12 000-174-063 Washer, 1.5" O.D. x 1.073" I.D. x 0.075" Thk. 3
13 000-094-097 Nut,1-14" Brass Water Box 4
14 000-052-023 Tee, 3/8" NPT Male Street 1
15 000-052-662 Nipple, 3/8" NPT x 1/4" M SAE 1
16 000-052-105 Insert, #68 (3/8" NPT x 1/2" Barb) 2
17 000-157-031 Switch, Side Mount w/ Bulkhead Fitting 1
18 000-169-167 Valve, Mechanical Incoming Water - Water Box 1
19 000-005-007 Float, Water Box 1
20 000-143-336 Screw, #10-32UNF x 0.25" Lg. Pan Head Phillips 1
21 000-057-052 Gasket, 1" Garden Hose 1
22 000-052-099 Insert, #26 (1/8" NPT x 3/8" Barb) 1
23 000-033-005 Clamp, Size #5 Hose 1
24 000-068-326 Hose, 3/8" Clear Braid Solution 1
25 000-041-365 Cover, 4" Round Poly Water Box 1
26 000-052-156 Tee, 1/4" Plastic Vacuum Insert 1
27 000-143-314 Screw, #8 x 1/2" Lg. Pan Head 6
28 000-174-032 Washer, 3/8" Flat 4
29 000-143-017 Screw, 3/8"-16UNC x 3/4" Lg. Hex Head 4
30 000-052-728 Bulkhead, 1/2" FPT x 3/8" FPT 1
31 000-052-754 Insert, #F816 (1/2" FPT x 1" Barb) 1
