HydraMaster MAXX 450D - Fig; Dash Assembly

Page 1-36 MAXX 450D/470/Diesel
HydraMaster Corporation
Item Part Number Description Qty
Dash Assembly Parts List
1 000-100-088 Panel, Main Dash - Maxx 450D/470D 1
2 000-100-096 Grill, Upper Dash 1
3 Fig. 1-13 Assembly, Lower Dash Plumbing Connection Panel - Maxx 4 1
4 Fig. 1-14 Assembly, Upper Dash Instrument Panel - Maxx 1
5 000-100-102 Panel, Perforated Grill 1
6 Fig. 1-15 Assembly, Control Panel 1
7 000-169-160 Valve, Chemical Metering 1
8 000-169-0171 Valve, 3-Way Ball O-Ring Style 1
9 000-074-030 Meter, Chemical Flow Raw 1
10 000-108-115 Protector, 5/8" Bumper 12
11 000-052-069 Nipple, 1/8" NPT Hex 3
12 000-052-078 Elbow, 1/8" NPT x 45° Street 1
13 000-052-531 Elbow, 1/8" NPT x 1/4" SAE 1
14 000-052-084 Elbow, 1/8" NPT Street 1
15 000-094-034 Nut, #10-24UNC Nylock 7
16 000-052-099 Insert, #26 (1/8" NPT x 3/8" Barb) 3
17 000-025-011 Cable, Choke (5 Foot) 1
18 000-094-098 Nut, 7/16"-24UNF - 2 Way Metering Valve 1
19 000-131-131 Trimlok, 3/8" x 1/8" 1
20 000-105-221 Plate, HydraMaster Name - Maxx 1
21 000-143-171 Screw, #10-24UNC x 1.25" Lg. Hex Head 7
22 000-174-001 Washer, #10 Flat 26
23 000-155-054 Spring, #10 Belleville Washer 10
24 000-143-134 Screw, #10-24UNC x 1.00" Lg Hex Head 11
25 000-174-036 Washer, #10 Flat Rubber Backed 6
26 000-084-013 Reflector 1.25" x 12" Transparent 1
27 000-094-004 Nut, #10-24UNC Hex 2
28 000-143-166 Screw, #10-24UNC x 0.38" Lg. Hex Head 4
29 000-174-030 Washer, 5/8" I.D. x 7/8" O.D. x 0.010" Thk. 1
30 000-174-062 Washer, 1/2" I.D. x 3/4" O.D. x 0.010" Thk. 1
