HydraMaster MAXX 450D - Chemical Jug Tray Assembly

MAXX 450D/470/Diesel Page 1-81
HydraMaster Corporation
Chemical Jug Tray Assembly Parts List
Item Part Number Description Qty
1 000-166-021 Tray, Chemical Jug - Outer - Weldment 1
2 000-166-025 Tray, Chemical Jug - Inner 1
3 000-078-039 Vacuum Inlet Stopper 1
4 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 2
5 000-174-019 Washer, 1/4" Lock 2
6 000-169-022 Valve, 1-1/2" Full Port Ball 1
7 000-052-226 Insert,1-1/2" NPT x 1-1/2" Barb (Grey) 2
8 000-052-182 Nipple, 1-1/2" NPT Close Galvanized 1
9 000-159-016 Jug, 5 Gallon Plastic Chemical - Standard 1
10 000-174-003 Washer, 1/4" Flat 4
11 000-015-720 Bracket, Apo Outlet Mounting - Weldment 1
12 000-027-014 Cap, Garden Hose 1
13 000-052-338 Insert, #1212 (3/4" NPT x 3/4" Barb) 1
14 000-057-055 Gasket, Garden Hose 1
15 000-169-009 Valve, 3/4" FPT Swing Check 1
16 000-174-050 Washer, 1" Flat 1
17 000-174-063 Washer, 1.5" O.D. x 1.073" I.D. x 0.075" Thk. 1
18 000-052-281 Nipple, 3/4" NPT x 3/4" Male Garden Hose 1
19 000-094-009 Nut, 1/4"-20UNC Hex Nylock 2
