Page 1-98 MAXX 450D/470/Diesel
HydraMaster Corporation
Maxx 450D/470/Diesel Hose Assemblies
Hose Hose
Part No. Descript.
From To Qty
068-015
1/4” Water to Water Heat Exchanger 12 in
(169-081)
068-020 Maxx Hi Temp Valve (169-050) Recovery Tank 47 in
068-030
5/32” APO (111-012) Hard Water MagnaClean 30 in
(163-056)
Upr. Primary Vac. Solenoid Valve Air Cylinder Valve (169-169) 12 in
(169-070)
Lwr. Primary Vac. Solenoid Valve Air Cylinder Valve (169-169) 8
1/2” in
(169-070)
Upr. Primary Vac. Solenoid Valve
3/16” Plastic Vac Tee (052-155) 4 in
(169-070)
Lwr. Primary Vac. Solenoid Valve
3/16” Plastic Vac Tee (052-155) 2 in
(169-070)
3/16” Plastic Vac Tee (052-155) 3/16” Plastic Vac Tee (052-155) 4 in
3/16” Plastic Vac Tee (052-155) Diverter Control Check Valve 11/2 in
(169-156) (Eng. Side)
3/16” Plastic Vac Tee (052-155) Upr. Primary Vac. Solenoid Valve 11/2 in
(169-156) (Blower Side)
Diverter Control Check Valve Engine 3 in
(169-156)
Diverter Control Check Valve CDS 4.8 Blower Adapter 80 in
(169-156) (001-041)
Gravity Feed Oil Cup (052-272) Blower Adapter (001-041) 49 in
0-30” Hg Vac. Gauge (074-017) Blower Adapter (001-041) 80 in
068-032 Pre- Water to Water Heat Exchanger 1” Barb x 1” Barb Tee (052-648) 5 in
formed (038-043)
Radiator w/ 90° 1” Barb x 1” Barb Tee (052-648) 8 in
