MAXX 450D/470D/Diesel Page 6-5
HydraMaster Corporation
10/24/02
Torque Chart
Torque
Pump Item Thread Inch Pounds Foot Pounds Nm
Plunger Retainer M6 55 4.4 6.2
Manifold Bolt M6 55 4.4 6.2
Valve Plugs M22 870 72.3 100.0
Bearing Case Screws M6 50 4.0 6.0
Crankcase Cover M6 50 4.0 6.0
Bubble Oil Gauge M28 45 3.6 5.0
Mounting Bolts M8 115 9.4 13.0
