Page 6-8 MAXX 450D/470D/Diesel
HydraMaster Corporation10/24/02
Cat Pump Parts List (cont.)
ITEM PART NO. DESCRIPTION QTY
167 43750 Spring 6
168 44565 Retainer, Spring 6
172 17615 O-Ring 75, Valve Plug 6
174 46756 Plug, Valve 6
185 46616 Manifold, Head 1
193 87870 Bolt, HSH, Manifold Head (M8x65) 8
196 22187 Plug, Discharge
3
/
8
”1
250 108-055 Protector, 3CP Cat Pump Shaft 1
260 114-003 Rail, Angle - 3CP Cat 1
265 30651 Complete Mounting Kit 1
270 30246 Pulley and Key Assembly 1
299 814841 Complete Head 1
300 078-271 Kit, Seal for 3CP Cat Pump 1
310 078-270 Kit, Valve for 3CP Cat Pump 1
350 30696 Valve Seal Removal Tool 1
