Page 1-28 MAXX 450D/470/Diesel
HydraMaster Corporation
Item Part Number Description Qty
Frame Assembly Parts List
1 000-055-155 Frame, Final Stock - Maxx 450D/470D 1
2 000-055-138 Frame, Engine Cover - Maxx 450D/470D 1
3 000-015-600 Bracket, Heat Exchanger Mount 1
4 000-015-629 Bracket, After Burner Mounting Saddle 1
5 000-033-115 Clamp, After Burner Mount 2
6 000-143-096 Screw, 3/8"-16UNC x 1.00" Lg. Hex Head 8
7 000-106-003 Plug, 3/8" NPT Hex 2
8 000-174-032 Washer, 3/8" Flat 7
9 000-094-015 Nut, 3/8"-16UNC Hex 2-Way Locking 4
10 000-143-012 Screw, 5/16"-18UNC x 0.75" Lg. Hex Head 12
11 000-174-018 Washer, 5/16" Lock 4
12 000-174-049 Washer, 5/16" Flat 4
13 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 2
14 000-094-010 Nut, 1/4"-20UNC Hex 4
15 000-108-115 Protector, 5/8" Bumper 12
16 000-060-010 Grommet, 1-5/16" I.D. 1
17 000-060-002 Grommet, Large Wiring 5
18 000-174-014 Washer, #10 Lock 4
19 000-143-327 Screw, #10-32UNF x 0.50" Lg. Hex Head 2
20 000-052-104 Insert, #66 (3/8" NPT x 3/8" Barb) 2
21 000-052-427 Bushing, 1/8" NPT x 1/8" FPT 1
22 000-106-001 Plug, 1/8" NPT 1
23 000-052-109 Insert, #F24 (1/8" NPT x 1/4" Barb) 1
24 000-033-119 Clamping Unit, HC-10-2-3, 2 Position 6
25 000-020-041 Bushing, Split, G-10-8 Clamping Unit 3
26 000-020-042 Bushing, Split, G-10-8 Clamping Unit 4
27 000-094-104 Nut, Stacking, N-10 Clamping Unit 8
28 000-143-199 Screw, Thread Adapter T-10, Clamping Unit 6
29 000-033-053 Clamp, 1-1/2" Cushion Loop 1
30 000-174-001 Washer, #10 Flat 5
