Page 1-42 MAXX 450D/470/Diesel
HydraMaster Corporation
Item Part Number Description Qty
Electrical Control Panel Assembly Parts List
1 000-100-100 Panel, Control Mount 1
2 000-074-110 Controller, Temp. Analog 1
3 000-012-010 Block, Terminal 10 Post 2
4 000-084-009 Lamp, Socket - Dashboard 4
5 000-084-004 Lamp, Replacement Guage 4
6 000-060-010 Grommet, 1-5/16" I.D. 2
7 000-056-020 Fuse Panel 1
8 000-056-030 Diode Panel 1
9 000-018-040 Circuit Breaker, 50 AMP 1
10 000-157-022 Switch, Relay 3
11 000-143-062 Screw, #10-24UNC x 0.75" Lg. Pan Head Phillips 4
12 000-094-034 Nut, #10-24UNC Nylock 10
13 000-143-166 Screw, #10-24UNC x 0.38" Lg. Hex Head 3
14 000-143-545 Screw, #8-32UNC x 1.00" Lg. Phillips Head 9
15 000-143-533 Screw, #10-24UNC x 0.25" Lg. Pan Head Phillips 2
16 000-174-014 Washer, #10 Lock 10
17 000-143-298 Screw, #8-32UNC x 1.50" Lg. Pan Head Phillips 1
18 000-033-044 Clamp, 3/8" Tube 1
19 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 1
20 000-072-010 Ignition Processor - 700G Daihatsu 1
21 000-072-009 Ignition Processor - 950G Daihatsu 1
22 000-029-016 Governor, Hall Affects Maxx 450D/470DD 1
23 000-029-030 Governor, Magnetic Pick Up - Maxx Diesel 1
