Page 1-56 MAXX 450D/470/Diesel
HydraMaster Corporation
Item Part Number Description Qty
Diverter Valve Actuator Assembly Parts List
1 000-015-772 Bracket, Diverter Air Cylinder Mounting 1
2 000-015-774 Bracket, Diverter Air Cylinder Foot - Top 1
3 000-015-774 Bracket, Diverter Air Cylinder Foot- Bottom 1
4 000-015-630 Bracket, Air Cylinder Extension 1
5 000-169-169 Valve, Air Cylinder 1
6 000-094-081 Nut, 5/16"-18UNC Hex 2-Way Locking 1
7 000-143-573 Screw, 5/16-18 Shoulder, 3/8" Dia x 1/2" 1
8 000-052-106 Insert, 1/8" NPT x 5/32" Barb x 90° 2
9 000-174-003 Washer, 1/4" Flat 4
10 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 2
11 000-094-009 Nut, 1/4"-20UNC Hex Nylock 1
12 000-143-009 Screw, 1/4"20UNC x 2.50" Lg. Hex Head 1
13 000-094-092 Nut, 7/16"-20UNF Hex Jam 1
14 000-174-019 Washer, 1/4" Lock 2
