Page 1-60 MAXX 450D/470/Diesel
HydraMaster Corporation
Item Part Number Description Qty
Blower MD 4007 Assembly Parts List
5 000-015-634 Bracket, Blower Foot Mount Rear 1
6 000-001-101 Adapter, 2-1/2" NPT x 3" M Slip 1
7 000-015-781 Bracket, Idler Mounting - Maxx/Javelin 1
8 000-150-055 Bolt, Idler Pulley Shoulder - Maxx 450D/470D 1
9 000-143-552 Screw, 7/16"-14UNC x 7.875" Lg. Hex Head Grade 5 1
10 000-154-113 Spacer, 0.790 ID x 1.090 Lg. Idler Pulley - Maxx w/ Sheet Fra 1
11 000-109-074 Pulley, AK41 Bored 7/8" 1
12 000-077-001 Key, #3 & #4 Vacuum Pump Drive 1
13 000-143-017 Screw, 3/8"-16UNC x 0.75" Lg. Hex Head Grd. 8 4
14 000-174-021 Washer, 3/8" Lock 4
15 000-052-069 Nipple, 1/8" NPT Hex 1
16 000-052-092 Tee, 1/8" FPT 2
17 000-052-057 Nipple, 1/8" NPT Close 1
18 000-052-084 Elbow, 1/8" NPT Street 1
19 000-052-293 Insert, #23 (1/8" NPT x 3/16" Barb) 3
20 000-033-117 Clamp, 1" Cushion Loop w/ 7/16" Mount Hole 1
21 000-020-019 Bushing, #H x 7/8" Bore 1
22 000-052-085 Elbow, 1/4" NPT Street 2
23 000-052-647 Nipple, 1/4" NPT x 4" Lg. 2
24 000-027-010 Cap, 1/4" NPT 2
25 000-094-105 Nut, 3/4"-16UNF Hex Zink Plated 1
26 000-094-106 Nut, 3/4"-16UNF Hex Jam - Zink Plated 1
27 000-109-100 Pulley, 6" Dual V Belt - Maxx 1
28 000-109-110 Pulley, Dual Belt Idler - Maxx 450D/470D 1
29 000-052-061 Bushing, 3/8" NPT x 1/4" FPT 2
30 000-143-018 Screw, 3/8"-16UNC x 1.00" Lg. Grade 8 6
31 000-174-005 Washer, 3/8" Flat 2
32 000-094-102 Nut, 7/16"-14UNC Two-Way Locking Hex 1
33 000-068-522 Hose, 3 “ x 2-1/4” Silicon w/ Clamps 1
34 000-174-032 Washer, 3/8" Flat 6
