216 HyPrecision Predictive waterjet pump Operator Manual 810120
9 – Installation
Installation
Operator interface: Adjustment screens
The adjustment screens on the operator interface let the user change the system configuration.
There are 3 ways to interact with the adjustment screens.
1. Touch a field with a border around it.
A numeric keypad opens. Touch Enter to save an entry. Touch Esc to go back 1 screen without saving the
entry.
2. Touch a square to turn a feature on (green) or off (gray).
Not all screens are used when installing the pump.
Touch the current screen symbol to go back 1 screen.
A field with no border means that the item is informational.
