Powermax105 Operator Manual 8-13
Install the air filter element (for metal guarded bowl)
5. You can see the white filter element and black retaining nut on the filter assembly. Unscrew (counterclockwise) the
plastic retaining nut that secures the filter element.
6. Replace the dirty element with the new white element.
7. Reinstall (clockwise) the original plastic retaining nut to finger-tight only.
8. Wipe away any oil, dirt, or other contaminants inside of the filter bowl to make sure it is clean.
9. Examine the O-ring at the top of the filter bowl.
O-ring
• If the O-ring is damaged, replace it with the thinner of the two O-rings in kit228695.
Use thinner O-ring.
• If the O-ring is not damaged, make sure it is lightly lubricated with silicone lubricant (027055 not included).
