Drive Wheel Assembly
Drive wheel assembly tasks are slightly different depending on the type: AdvanceDrive™ or XtremeDrive™.
NOTE: Installation instructions are provided with the replacement drive wheels and are accessible online at www.hysecurity.com.
A quick look at the drive wheel assembly is shown below. Tighten drive wheel mounting bolts to 25 ft lb.
Collared Drive Wheels (pre-2015) AdvanceDrive Wheels
AdvanceDrive Wheels assembled AdvanceDrive and XtremeDrive Wheel combo
