HySecurity SlideDriver 30F User Manual

www.hysecurity.com © 2019 Control Panel Overview MX3630-01 Rev. J 49
STC Board, Power Supply Board and Display
The Smart Touch Controller provides connections for a multitude of peripherals and accessory devices. The
Power Supply Board offers 8 common bus terminals, 4 terminals (24VAC) and 3 terminals (24VDC) with a 3A
maximum draw. The touch-sensitive keypad and 32-character display connects to the STC with a waterproof
ribbon cable. For more information about STC Inputs and connections, refer to STC Inputs & Wiring on page
68. For more information about the display programming, operator modes and keypad navigation, refer to
Display & Menu Options on page 50.
STOP BUTTON
OPEN BUTTON
CLOSE BUTTON
REMOTE OPEN AND
RADIO CONTROL
OPEN/CLOSE
1
OPEN PARTIAL
INTERLOCK OPEN
TIME CLOCK OPEN
FREE EXIT DETECTOR
DISABLE EXIT DETECTOR
DISABLE CLOSE TIMER
INSIDE OBSTRUCTION
VEHICLE DETECTOR
OUTSIDE OBSTRUCTION
VEHICLE DETECTOR
SHADOW/RESET
VEHICLE DETECTOR
EDGE SENSOR
PHOTO EYE POWER
24 VOLTS COMMON
PHOTO EYE POWER
DO NOT USE
PHOTO EYE
OPEN DIRECTION
DO NOT USE
PHOTO EYE
CLOSE DIRECTION
DO NOT USE
CHARGER
AC LOSS
LOCK INTERLOCK
EMERG CLOSE
FIRE DEPT OPEN
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
Smart Touch Controller
LIMIT DUAL GATE
RADIO OPTIONS
DRIVE
POWER
RS485
MOTOR USER 1
USER 2
USER 3
VEHICLE DETECTORVEHICLE DETECTORVEHICLE DETECTOR
STOP/BUZZER
FREE EXIT
INSIDE OBSTR
OUTSIDE OBSTR
SHADOW RESET
WIEGAND
HySecurity
COM
NO
MX000585
VERSION
S/N
RS232
DISPLAY
VEHICLE DETECTOR
COM COMA B
RPM
COMOPEN S1+24V +24V
STATUS
LED
24V AC Accessory power
+ 24
V
D
C
Power Connector
Power Supply Board
COMMON
Smart Touch Controller
EDGE SENSOR
PHOTO EYE
OPEN DIRECTION
PHOTO EYE
SENSOR 1
SENSOR
COM
SENSOR 2
EDGE SENSOR
PHOTO EYE POWER
24 VOLTS COMMON
PHOTO EYE POWER
PHOTO EYE
OPEN DIRECTION
PHOTO EYE
CLOSE DIRECTION
DO NOT USE
DO NOT USE
SENSOR 1
SENSOR
COM
SENSOR 3
SENSOR 2
DO NOT USE
DO NOT USE
Ribbon cable
STC Display & Keypad:
Provides push button programming
and displays menu codes, faults,
alerts & errors. Refer to STC Inputs &
Wiring on page 68.
Smart Touch Controller:
Provides inputs for peripherals & accessories, 2 electro-
mechnical user relays (250VAC, 10A), one solid state user
relay (30VDC, 3A). For more information, refer to STC
Inputs & Wiring on page 68.
Common (COM) power
terminal strip
UL 325 - 2016
Label
Pre - 2016
Label
Updated silk
screen label
incorporated
January 2016.
