HySecurity SlideDriver 30F User Manual

www.hysecurity.com © 2019 Display & Menu Options MX3630-01 Rev. J 63
Installer Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
PC 1 NO CONTACT
PHOTO EYE
OUTPUT
0 = Normally Open NO input
1 = Normally Closed NC input
(monitored)
This menu item only appears when UC is
set to 4. Default setting is photo eyes with
Normally Close outputs. Optional setting
0 requires a Normally Open (NO) output.
When set for NC, connection is monitored
and any short circuit fault will generate
a FAULT 2 alert which requires a STOP
or RESET button press to re-enable gate
operation.
COM
+24V
COM
PHOTO EYE
CLOSE
DIRECTION
GC 0 NO INPUT
GATE EDGE
OUTPUT
0 = Normally Open NO input
1 = Normally Closed NC input
(monitored)
This menu item only appears when UC is
set to 4. Default setting is edge sensor with
Normally Closed (NC) output. Optional
setting of 0 requires an (NO) output.
COM
+24V
COM
EDGE SENSOR
TC 1 (INTLOCK)
TIME CLK/INTLOCK
0 = TIME CLK (Select Time Clock)
1 = INTLOCK
(Select Open Interlock)
Congures the input at Terminal No. 7 on
the STC to be either for the gate interlock
function, or for an external time clock to
open input. The default setting is (TC_1) for
the interlock function.
INTERLOCK
OPEN (#7)
COM
DT 0 FREE EXIT
DISABLE FUNCTION
0 = Disable Free Exit
1 = Disable Close Timer
Congures BLOCK EXIT input to disable
either Free Exit Detector function or,
alternately, Close Timer function. Default
setting disables free exit detector.
NOTE: Free exit is disabled when gate is at
its closed limit. If closed limit is not tripped,
free exit continues to work normally.
DISABLE EXIT
DETECTOR (#9)
COM
OR 1 REVERSE
OUTSIDE OBS LOOP
0 = Pause closing only
1 = Enable reversing to open
2 = Ignore and continue closing*
Default is for full reversal when Outside
Obstruction Loop is triggered while closing.
A setting of 0 causes gate to only pause
when triggered. Gate closure ontinues as
soon as loop is clear again.
OUTSIDE OBS
LOOP (#11)
COM or
connection to
Hy5B detector
IR 1 REVERSE
INSIDE OBS LOOP
0 = Pause closing only
1 = Enable reversing to open
2 = Ignore and continue closing*
Default is for full reversal when Inside
Obstruction Loop is triggered while closing.
A setting of 0 causes gate to only pause
when triggered. Closure begins as soon as
loop is clear again.
INSIDE OBS
LOOP (#10)
COM or
connection to
Hy5B detector
HD 1 HOLD CLOSE
Center Loop Hold
0 = Hold Open only
1 = Hold Close and hold Open
Swing gates: Congures the function of the
Center Loop (Shadow Loop) when triggered:
Setting 1 - holds the gate from starting open
and from starting close. This setting prevents
opening and closing of the gate when the
Center Loop is tripped if the gate is on
either (opened or closed) limit switches.
Setting 0 - holds the gate from starting
closed. This setting prevents closing when
on the open limit switch.
CENTER LOOP
(#10)
COM or
connection to
Hy5B detector
NOTE: The shaded Installer Menu items do not appear when Build Year is set to 2 (BY 2). Exceptions exist for barrier arms, CRASH
products, operators set to pre-2016 and Usage Class IV provisions.
