8000 SRM 707 Wheel and Tire Replacement
Wheels, Install
WARNING
When the wheels have been installed, check
all wheel nuts after 2 to 5 hours of operation.
Tighten the nuts to the correct torque. When
the nuts stay tight for 8 hours, the interval for
checking can be extended to 250 hours.
Install wheel on hub. Tighten nuts as shown in the
Maintenance Schedule. If the wheels are the two-
piece rims, make sure nuts that fasten rim halves
together are toward brake drum when they are in-
stalled.
Dual Drive Wheels, Install
WARNING
When the whe
els have been installed, check
all wheel nu
ts after 2 to 5 hours of operation.
Tighten th
e nuts to the correct torque. When
the nuts st
ay tight for 8 hours, the interval for
checking c
an be extended to 250 hours.
NOTE: Some
lift trucks have dual drive wheels. The
following
procedures describe the steps to install the
dual sets o
fwheels.
1. Install in
ner wheel on hub. See Figure 48.
Tighten nu
ts as shown in the Maintenance
Schedule
. If the wheels are the two-piece rims,
make sure
nuts that fasten rim halves together
are towar
d brake drum when they are installed.
2. Install s
pacer to axle shaft. Tighten nuts to
98 N•m (72
lbf ft).
3. Install o
uter wheel on spacer. Tighten nuts
as shown i
n the Maintenance Schedule. If the
wheels a
re the two-piece rims, make sure nuts
that fasten rim halves together are toward brake
drum when they are installed.
1. INNER WHEEL
2. SPACER
3. OUTER WHEEL
4. AIR VALVE
EXTENSION
Figure 48. Dual Drive Wheels Installation
SOLID RUBBER TIRE, CHANGE H45-65XM
MODELS
WARNING
Wheels must be changed and tires repaired by
trained personnel only.
Always wear safety glasses.
1. Put lift truck on blocks as described in How to
Put Lift Truck on Blocks at the beginning of this
section.
2. Remove wheel nuts and remove wheel and tire
from lift truck. Lift truck tires and wheels are
heavy.
67
