Hytera PD78X Series User Manual

Hytera DMR System Planner
90
Figure 3.1.1-2: Non-display Model
No. Part Name No. Part Name
1 SK1 (Side Key 1) 8
Radio On-Off/Volume
Control Knob
2 PTT Key 9 Microphone
3 SK2 (Side Key 2) 10 Accessory Jack
4 TK (Top Key) 11 Battery Latch
5 Channel Selector Knob 12 Antenna
6 Speaker 13 Belt Clip
7 LED Indicator 14 Battery

Hytera PD78X Series Specifications

General

Brand	Hytera
Model	PD78X Series
Category	Portable Radio
Language	English
