3.1.1 Product Overview
Figure 3.1.1-1: Display Model
No. Part Name No. Part Name
1 SK1 (Side Key 1) 11 LED Indicator
2 PTT Key 12 Antenna
3 SK2 (Side Key 2) 13
Radio On-Off/Volume
Control Knob
4 TK (Top Key) 14 Accessory Jack
5 Channel Selector Knob 15 Back Key
6 Microphone 16 Up Key
7 LCD Display 17 Down Key
8 OK/Menu Key 18 Battery Latch
9 Speaker 19 Belt Clip
10 Numeric Keypad 20 Battery
