Reaction Arm or HYTORC Washer
Use the appropriately sized reaction arm or HYTORC Washer based on your application. The LITHIUM is
usually supplied with a reaction arm in standard length. However, a custom reaction arm may have been
delivered for your special application.
WARNING!
Never modify a Reaction Arm! Changes in the reaction arm may lead to per-
sonal injury or damage to the tool.
NOTE:
Reaction modications result in loss of warranty for the reaction arm and the
LITHIUM Gun. If you need a custom reaction arm, please consult with your
local TORQUE GUN dealer.
Figure 3 - HYTORC Washer and Driver
10
BREAKTHROUGH PRODUCTS FOR INDUSTRIAL BOLTING
Figure 2 - Reaction Arm
