APPENDIX A
LITHIUM GUN BLOCK DIAGRAM
Figure 20 - Lithium GUN Block Diagram
POWER IN
36V DC
MOTOR
GEAR
BOX
SOCKET
DRIVE
USER INTERFACE
CONTROLLER
BOARD (UIC)
MOTOR DRIVE
CONTROLLER BOARD
(MDC)
TRIGGER
SWITCH
35
BREAKTHROUGH PRODUCTS FOR INDUSTRIAL BOLTING
