5. Calibration routine will now begin: Be aware, the gun will now operate WITHOUT prompting the
operator to also press one of the back buttons.
• When “Cal Point X – Y operate gun & record torque” is displayed: (Note: X = the current
calibration point, Y = the current sample of the calibration point).
- Pull and hold the trigger.
- The gun will torque until it reaches its calibration point.
- When it stops, enter the nal torque using the rear buttons.
• The torque gun will now temporarily store this calibration point.
• Repeat at the gun prompts.
6. When all calibration points are completed, the torque gun will ask if you would like to save or
cancel. If you select “save”, the temporary calibration data will now be locked into memory.
Note: If the rst calibration point generated torque values ABOVE the minimum rated torque for the tool
you are calibrating, the calibration has failed. If by the LAST calibration point, the gun failed to generate
torque that EXCEEDS the maximum rated torque of the gun, the calibration has failed. In either case
please contact The Torque Gun Company for support.
34
