OPERATION
General
Each Lithium Torque Gun is supplied completely assembled and ready for use. A full kit contains:
• Lithium Torque Gun
• Two 36V Li-ion 3.9Ah Battery Packs
• 36V Battery Charger
• Battery Charger Power Supply
• Reaction Arm
Figure 10 - LITHIUM Gun Overview
REACTION
ARM
GEAR
BOX
BEARING
HOUSING
TRIGGER
SWITCH
36V
BATTERY PACK
VENTS
MAIN
DISPLAY
STATUS
LED
