Important Preparation Steps for the HYTORC Washer
• Before using the HYTORC Washer the connection and the connection elements must be carefully
checked and cleaned.
• The HYTORC Washer must be completely dry and free from oil and grease.
• The nut to be mounted above the HYTORC Washer must be lubricated according to the
specications and application requirements.
Important Installation Steps for the HYTORC Washer
• Slide bolts through the bolt hole.
• Determine which side of the connection is more suitable for fastening and tightening the bolts.
(Working space for bolting, lighting, accessibility).
• Install the clean, dry nut on the opposite side from which you want to tighten.
• Install the HYTORC Washer on the side which you want to tighten by rotating the bolt clockwise
until it is hand tight.
• Now install the lubricated nut (on the same side as the HYTORC Washer) by turning it clockwise
until it is hand tightened against the HYTORC Washer.
CAUTION
For a correct installation only 3 to 4 threads should be seen beyond the nut to
be tightened.
Once all the bolts are prepared following the previous instructions for assembly, tighten the nuts using
the HYTORC Washer Driver.
30
BREAKTHROUGH PRODUCTS FOR INDUSTRIAL BOLTING
Figure 16 - HYTORC Washer Installed
