Chapter 8 Parameter
POWER CON
PCON-CB/LC
195
[36] Velocity override (Parameter No.46)
No. Name Symbol Unit Input Range
Default factory
setting
46 Velocity override OVRD % 0 to 100 100
When move commands are issued from the PLC, the moving speed set in the “Velocity” field of
the position table can be overridden by the value set by this parameter.
Actual movement velocity = [Velocity set in the position table] × [setting value in Parameter
No.46]
Example) Value in the “Velocity” field of the position table: 500mm/s
Setting in Parameter No.46 20%
In this case, the actual movement speed becomes 100mm/s.
The minimum setting unit is 1% and the input range is 1 to 100%.
(Note) This parameter is ignored for move commands from a teaching tool such as PC
software.
[37] PIO jog velocity 2 (Parameter No.47)
No. Name Symbol Unit Input Range
Default factory
setting
47 PIO Jog velocity 2 IOV2
mm/s
(deg/s)
1 to Actuator’s max.
speed
(Note 1)
100
This is the setting of JOG operation velocity when 1 is set in the JOG velocity / inching distance
switchover signal JVEL for field network type.
Set the appropriate value considering how the system is to be used.
Note 1 The maximum speed is limited to 250mm/s.
[38] PIO inch distance, PIO inch distance 2 (Parameter No.48, No.49)
No. Name Symbol Unit Input Range
Default factory
setting
48 PIO inch distance IOID mm
0.01 to 1.00
(Note 1)
0.1
49 PIO inch distance 2 IOD2 mm
0.01 to 1.00
(Note 1)
0.1
When the selected PIO pattern is “1” (Teaching Mode), Parameter No.48 defines the inching
distance to be applied when inching input commands are received from the PLC. Parameter
No.49 defines the inching distance when 1 is set in the JOG speed / inching distance
switchover signal JVEL for field network type.
Note 1 The maximum allowable value is 1 mm.
[39] Load output judgment time period (Parameter No.50)
No. Name Symbol Unit Input Range
Default factory
setting
50 Load output judgment time period LDWT msec 0 to 9999 255
This parameter defines the time taken to judging whether torque level status signal (TRQS) is
ON.
If the command torque exceeds the value set in “Threshold” of position data for the time set by
this parameter during pressing operation, torque level status signal (TRQS) is turned ON.
Refer to 3.2.4 [4] or 3.2.5 [3] Pressing Operation for the details of the pressing operation.
