4. Install the console switch behind the flat panel monitor and keyboard tray using
two screws from the miscellaneous hardware kit.
8
1
A
2
3
4
5
6
7
1
A
2
Console
switch screw
Console
switch screw
5. Route the keyboard, video, and mouse cables through the slot in the left-side
bracket on the console switch; then, connect the keyboard, video, and mouse
connectors to the console switch.
6. Refer to the documentation that comes with your console switch for information
about connecting your flat panel monitor, space-saver keyboard, and servers to
the console switch.
1U Flat Panel Monitor Console Kit 97
