Rack Enclosure (Type 9306 Model 200) Options FRU
Hardware Kit for NetBAY Power Distribution Units 09N9671
Flat Panel Monitor Rack Mount Kit (T54A, models AG1, AW1; T55) 37L6888
Flat Panel Adapter Hinge - R.H. & L.H. (T54A, T55) 09N9678
Flat Panel Adapter Misc. Hardware Kit – Includes: Hinge Cover (1), Power Supply Cover
(1), Mounting Stud (1), Bumper (2), Cable Access Cover (1), M4 X 12 Screw (4), M4 X 8
Screw (2), 14 inch Soft Tie Wrap (1), T54A power supply spacer (1)
00N8693
Flat Panel Adapter Display Housing – Includes: Power Supply Cover (1), Base Housing (1),
Cable Access Cover (1), Bottom Stand
00N8694
Type 9306 Model 900/910
Features
The IBM Server 9306-900/910 Rack enclosure is an industry-standard, 19-inch rack
that houses and controls multiple IBM PC Servers/IBM Servers and related
equipment.
v Model 900 has optional side panels, solid front door, and perforated rear door.
v Model 910 has side panels and perforated front and rear doors.
Locations
The following sections contain information on specific equipment locations.
Note: For instructions on how to power-off the rack, see “Powering off the rack” on
page 3.
Side Panel
Locked Unlocked
34 Hardware Maintenance Manual: IBM PC Server/Enterprise Racks Types 9306, 9308
