Note: There are two types of Power distribution units available:
v High voltage
v Low voltage
Installing a PDU vertically
Use the following general procedure to install a PDU vertically in the side of your
rack cabinet:
1. See the PDU documentation for detailed installation information.
Note: If the PDU has a circuit breaker switch, verify that the switch is in the Off
position before you install the PDU in your rack cabinet.
Figure 30. Power distribution horizontal installation
Vertical mounting plate
with PDUs
Cable-management bracket
Figure 31. Installing a PDU vertically in a rack cabinet
110 Hardware Maintenance Manual: IBM PC Server/Enterprise Racks Types 9306, 9308
