The following illustration shows the location of expansion slots on the system
board.
AGP slot
PCI slot 1
PCI slot 2
PCI slot 3
PCI slot 4
PCI slot 5
Adapter considerations
Before you install adapters, understand the following:
v Follow the instructions that come with the adapter in addition to the instructions
in this chapter. If you need to change the switch or jumper settings on your
adapter, follow the instructions that come with the adapter.
v You can install full-length adapters in all 5 PCI slots.
v Your computer supports 5.0 V and universal PCI adapters; it does not support
3.3 V adapters.
v For a list of supported options for your computer, refer to
http://www.ibm.com/pc/support on the World Wide Web.
Chapter 5. Installing Options 33
