might also need to perform certain preinstallation activities. Some of the steps are
required only during the initial installation of an option.
1. Read “Safety Information” on page vii, “Handling static-sensitive devices” on
page 30, and the documentation that comes with your drive.
2. Choose the bay in which you want to install the drive.
3. Check the instructions that come with the drive to see if you need to set any
switches or jumpers on the drive. If you are installing a SCSI device, be sure to
set the SCSI ID for that device.
Installing a drive in bay 2 or 4
Do the following to install a drive in bay 2 or 4.
Attention
When handling static-sensitive devices, take precautions to avoid damage
from static electricity.
EMC shield
Filler panel
1. Read the information in “Preinstallation steps (all bays)” on page 37.
2. Turn off the computer and attached devices and disconnect the external cables
and power cords.
3. Remove the side cover (see “Removing the side cover” on page 30 for details).
4. Remove the support bracket see “Removing the support bracket” on page 31.
5. Use a screwdriver to pry the filler panel and EMC shield away from the
computer.
38 IntelliStation M Pro: User Guide
