Name AIX
Location
Code
Location
Code
Physical
Connection
Logical
Identification
Keyboard Port 01-K1-00 P1/K1 J59 Base Address
0x0060
Mouse Port 01-K1-01 P1/O1 J56 Base Address
0x0060
Serial Port 1 01-S1 P1/S1 J24 Base Address
0x03F8
Serial Port 2 01-S2 P1/S2 J23 Base Address
0x02F8
Parallel Port 01-R1 P1/R1 J49 Base Address
0x0378
Ethernet Port 10-60 P1/E1 J45 Host Bridge ID00,
Device 12
SCSI Port 10-80 P1/Z1 J33/J38 Host Bridge ID00,
Device 16
Tablet Port 01-Q1 P1/Q1
Card in PCI Slot 1 1P-08 P1.1-I1 J1 PCI Bridge ID01,
Device 18
Card in PCI Slot 2 10-b0 P1.1-I2 J2 Host Bridge ID00,
Device 22
Card in PCI Slot 3 10-90 P1.1-I3 J3 Host Bridge ID00,
Device 18
Card in PCI Slot 4 1P-18 P1.1-I4 J5 PCI Bridge ID01,
Device 19
Card in PCI Slot 5 1P-10 P1.1-I5 J4 PCI Bridge ID01,
Device 19
Base CDROM in Bay
2
P1-Z1-A3 Primary SCSI Bus ID
3
Media Drive in Bay 3 P1-Z1-A2 or
A6
Primary SCSI Bus ID
2 or 6
DASD in Bay 4 P1-Z1-A4 Primary SCSI Bus ID
4
DASD in Bay 5 P1-Z1-A5 Primary SCSI Bus ID
5
Fan # 1 F1 J27/J30
Operator Panel L1 J41
Power Supply V1 J7/J8/J2/J9
Chapter 5. Location Codes (Model 150 only) 5-3
