Specifications (for 7043 Models 140, 150, and 240)
The mechanical packaging, cooling, power supply, and environmental requirements
for the workstation is shown in the following:
Dimensions
In horizontal orientation
– Height - 165 mm (6.5 inches)
– Depth - 460 mm (18.1 inches)
– Width - 420 mm (16.5 inches)
In vertical orientation
– Height - 450 mm (17.7 inches)
– Depth - 460 mm (18.1 inches)
– Width - 235 mm (9.25 inches)
Weight
14.5 kg (29 lb) Minimum to 18.2 kg (40 lb) Maximum
Maximum Support Capacity (Horizontal Position)
27.3 kg (60 lbs)
Operating Environment - Class B
Temperature - 16° to 32°C (60° to 90°F)
Humidity - 8% to 80% noncondensing
Maximum Altitude - 2135 m (7000 feet)
Power Source Loading
0.3k VA typical
0.5k VA maximum
Power Supply
250 watts
1-4 7043 43P Series Service Guide
