System Board Jumper Settings (for Model 150)
For a more complete description of the function of these jumpers, see the system
unit User's Guide.
Jumper Description Settings
J15 Remote Power-up Default: Remote power-up disabled.
To enable Remote power-up, place
jumper on the two pins closest to the
rear of the system unit.
J32 Privileged-Access Password Default: disabled.
To enable the writing or changing of
the privileged-access password, place
jumper on the two pins closest to the
rear of the system unit.
J35, J36 SCSI Security Default: external SCSI enabled
To disable external SCSI connector,
move the jumper on J35 to the front
two pins, and the jumper on J36 to the
right two pins.
J20 Power-On Password Default: power-on password enabled
(can be set).
To disable the power-on password (for
instance, if it has been forgotten), place
jumper on the two rightmost pins.
Chapter 1. Reference Information 1-15
