You can obtain the planning tables and charts from www.ibm.com/support. The planning information
provides guidelines for completing the planning tables and charts. These tables include the location of
hardware, cable connection, and conguration data information that you need to complete the
installation procedures. Go no further with these instructions until you are satised that all the
information is correct and valid.
2. The label on the main shipping box indicates features that were shipped. Make sure that the contents
and quantity match the order.
The following feature codes are included:
• Each of the following:
– Feature code 3001: initial SAN Volume Controller 2145-SV1 node, quantity 1
– Feature code 3002: additional SAN Volume Controller 2145-SV1 node, quantity 1
– Optional feature code 3003: spare SAN Volume Controller 2145-SV1 node.
• Optional features as listed in "Optional features" in the documentation.
• One of the following country-specic SAN Volume Controller 2145-SV1 power cable feature codes:
9716, 9717, 9718, 9719, 9720, 9721, 9722, 9723, 9725, 9726, 9731, 9732, 9733, 9734, 9735,
9736, or 9737.
3. Check that the correct part set has been shipped for the feature codes. Unless otherwise stated, the
feature code contents are in the main box.
• Feature codes 3001 and 3002 ship the same parts. Verify that you have the listed parts:
– SAN Volume Controller 2145-SV1 node
– Part number 01EJ334: SAN Volume Controller 2145-SV1 rail kit, quantity 1
– Part number 01EJ335: SAN Volume Controller 2145-SV1 Cable-management arm assembly,
quantity 1
– The support rail kit contains a number of components within its box. Verify that you have the
following items:
- One left side rail
- One right side rail
- Four M6 screws
• Feature codes 9716, 9717, 9718, 9719, 9720, 9721, 9722, 9723, 9725, 9726, 9731, 9732, 9733,
9734, 9735, 9736, and 9737 each ship a single power cable. Use the power plug that is appropriate
to your location unless you are connecting to a rack-mounted power distribution unit.
• SAN Volume Controller publications: ship group (one box of publications per pair of 2145-SV1
nodes):
– SAN Volume Controller Publications CD
– SAN Volume Controller Read First
– IBM Systems Safety Notices CD
– IBM SAN Volume Controller Model 2145-SV1 Hardware Installation Guide
– SAN Volume Controller License Information for SAN Volume Controller CD
– SAN Volume Controller Statement of Limited Warranty flyer
– Environmental Notices CD
– IBM license information for machine code
– Other miscellaneous flyers
If feature codes 5305, or 5325 are not ordered for Fibre Channel connection, you must supply your
own ber-optic Fibre Channel cables. Make sure that four cables per adapter are available.
Chapter 2. Installing the SAN Volume Controller 2145-SV1 hardware
19
