Table 18. Other expansion enclosure parts (continued)
FRU Part Number Description Comments
00AR439 6 m 12 Gb SAS Cable (mSAS HD)
01LJ114 Rail kit
01LJ116 Front fascia (4U front cover)
01LJ118 Display panel assembly
01LJ120 PSU fascia (1U cover) The fascia must be removed to access
the power supply units.
01LJ122 Power supply unit (PSU) The expansion enclosure contains 2
PSUs. Each PSU requires a C19/C20
power cord.
01LJ124 (for use
with enclosure
FRU P/N 01LJ112)
01LJ860 (for use
with enclosure
FRU P/N 01LJ607
Secondary expansion module The expansion enclosure supports two-
secondary expansion modules.
CAUTION: Use caution when
you are removing or replacing a
secondary expansion module
from an enclosure with FRU part
number 01LJ112. Avoid contact
with the connectors on the main
board.
01LJ126 Fan module The expansion enclosure contains four
fan modules.
01LJ128 Expansion canister
01LJ130 Cable management arms (CMA) The part contains the upper and lower
CMA.
01LJ132 Top cover
01LJ134 Fan interface board
01LJ607
Note: Replaces
enclosure FRU P/N
01LJ112.
Enclosure Includes the drive board, signal
interconnect board, and internal power
cables, in an otherwise empty
enclosure.
39M5388 16A power cord C19/C20 2 m
Connecting the components
After installing the rails and enclosures in the rack, the Storwize V5100 control enclosures are connected
to power, the network, and any optional expansion enclosures.
After all cabling connections are completed, the system components are powered on.
70
Storwize V5100 : Quick Installation Guide for MTM 2078-424, 2078-12F, 2078-24F, 2078-92F, and 2078-
U5B
